Тэжээлийн блок GPS-3030D

  • үнэ: 690,000 төг

  • Тэжээлийн блок 30В, 3А
  • - Light and Compact Design
  •
    - 0.01% High Regulation
  •
    - Constant Voltage and Constant Current Operation
  •
    - Remote Control for External Programmability
  •
    - Internal Select for Continuous or Dynamic Load
  •
    - Low Ripple and Noise
  •
    - Overload and Reverse Polarity Protection
  •
    - Series or Parallel Operation
  •

DC OUTPUT
Output Volts (V) Output Amps (A)
GPS-3030D 0 ~ 30 0 ~ 3
CONSTANT VOLTAGE OPERATION
Regulation Line regulation≦0.01% + 3mV
Load regulation≦0.01% + 3mV (rating current≦3A)
Load regulation≦0.01% + 5mV (rating current > 3A)
Ripple & Noise ≦0.5mVrms 5Hz ~ 1MHz (rating current≦3A)
≦1mVrms 5Hz ~ 1MHz (rating current > 3A)
Recovery Time ≦100μS ( 50% load change, minimum load 0.5A )
Temp. Coefficient ≦300ppm/°C
Output range 0 to rating voltage continuously adjustable
CONSTANT CURRENT OPERATION
Regulation Line regulation≦0.2% + 3mA
Load regulation≦0.2% + 3mA
Ripple Current ≦3mArms
Output Range 0 to rating current continuously adjustable (Hi/Lo range switchable)
METER
Analog V-meter and I-meter
2.5 class
Dimensions 50 x 50 mm
Digital 31∕2 digital 0.5″ LED display (3030D)
31∕2 digital 0.39″ LED display (3030DD)
Accuracy ±(0.5﹪of rdg + 2 digits)
INSULATION
Chassis and Terminal 20MΩ or above (DC 500V)
Chassis and AC Cord 30MΩ or above (DC 500V)
POWER SOURCE
AC 220V±10%, 50Hz
ACCESSORIES
User manual x 1
Power cord x 1
Test lead GTL-105 x 1
European test lead GTL-201A (optional)
DIMENSIONS & WEIGHT
128(W) x 145(H) x 285(D)mm
Approx. 5kg
