Тусгаарлагчийн эсэргүүцэл хэмжигч UT512

UT512 Insulation Resistance Tester

1. Large 9999 display with 30-segment analog bar graph

2. PI/DAR measurements

3. Comparison, upper and lower limit functions

4. Continuous measurement mode

5. Auto power off

6. 18-group data storage

7. Backlight

8. Auto current discharge and high-voltage output alarm

9. Power adapter

10. Time measurement mode, auto measure within 15 minutes

11. USB interface and PC software

12. Low battery and over range indications

Specifications		Range	UT512
Insulation resistance (Ω)	Test voltages	500V~2500V	0%~20%
	500V	0.5MΩ~5GΩ	±(3%+5)
	1000V	2MΩ~10GΩ	±(3%+5)
	1500V	5MΩ~20GΩ	±(3%+5)
		10MΩ~100GΩ	±(3%+5)
DC voltage (V)	600V		±(2%+5)
AC voltage (V)	600V		±(2%+5)
Short-circuit current			<1.8mA
Features
Auto range/Auto power off			√
Low battery indication			√
Data storage			18
Comparison measurement			√
Polarization index (PI)			√
Dielectric absorption ratio (DAR)			√
USB interface			√
Analog bar graph			30
LCD backlight			√
Over-range warning			√
High voltage indication			√
Timing measurement	Around 15 minutes		√
General Characterisitics
Power	1.5V battery (LR14) x 8
Display	123mm x 58mm
Product color	Red and grey
Product net weight	1.8kg
Product size	202mm x 155mm x 94mm
Standard accessories	2pcs of one plug test lead to one alligator clip (black and green), 1pcs of two plugs test lead to one alligator clip (red), batteries, USB cable, PC software CD, power adaptor
Standard individual packing	Gift box, tool box, English manual
